DC12V 3D bumper car tube

 DETAILS:

1.180LEDs/M, 60IC/M, addressable ws2811 ic led bumper car tube.

2.3 chips SMD5050 RGB adapt as light source

3.IP65, IP66, IP67, IP68 Waterproof

4. WS2811 IC, 60pixels per meter (1IC control 1LEDs, ws2811 ic built inside of the the smd5050 rgb led).

5. waterproof

6. Fatanstic 3D view led tube for bumper car

7.Aboundant color modes, up to thousands of color change modes can be put in the programs

8.Work with LED control system could get Jumping, fading, flashing, dimming mode

9.Users can cut every 3 LEDs, Continuous light connection

10.amusement 3D tube bumper car led tube.

Datasheet:

Products Name

amusement bumper car led tube 3D view

Model NO.

SJ-100180-2811

Power Consumption

43W/Meter

Work Voltage

DC12V

IC model

WS2811

LED Quantity

180pcs SMD5050RGB ws2811

Color

Full color(ICRGB)

Dimension

1000*30mm

Waterproof Grade

IP65,IP66,IP67, IP68

Work Temperature

-40-60°C

Life-span

50,000H

Certificate

CE&RoHS

Warranty

2 years

Wire connection:
1) Signal wire: DC+,GND,DAT,CLK
2) DC+ and GND connect to power supplier;DAT and CLK connect to controller
3) Relative Controller: SPI controller support ws2811; when use DMX decorder, can connect to DMX system
4) Support online control

5) Make sure the connection is correct according to the diagram
6) Pay attention to the parameters limit of voltage. DO NOT run over the peak value.

7) 60pixels ws28111c black pcb aluminum housing led light bar ws2812b
